GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 8-184 Section 8-7 - Mechanical Option Installation instruction

8-7-14 Printer VCR DVD Fixture Top Installation (MD-800) (cont’d)

7.) Install DVD hide bracket by screwing 2 screws(2159633, BH M4x8).

Figure 8-301 Printer VCR DVD Fixture Top installation (LQ MD800)
