LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 9-18 Section 9-9 - Cables
709 Peripheral AC Power Cable 5165244
Connect one side (Label
CON5) to Label CON5 of
AC Out Cable and another
side (Label: CON6) to Label
CON6 of ARP Assy
1 1 Yes Yes Yes
710 AEXP Cable 5172066
Connect one side (Label
J13) to Label PCB Silk J13
of Syscon Assy
and another side (Label:
J15) to Label J15 of ARP
Assy
1 1 Yes Yes Yes
711 DCWD Cable II Assy 5257056
Connect one side to DCWD
Bracket and another
side(Label: J7) to PCB Silk
J7 of CWD64 Assy
1 1 Yes Yes Yes
712 IEC Type ECG CABLE 5341188
ECG Patient cable only for
Japan
1 1 Yes Yes Yes
713 AHA Type ECG CABLE 5341189
ECG Patient cable for Asia,
US, and Europe
1 1 Yes Yes Yes
Item Part Name FRU Number Description Qty FRU R1.0.x R2.0.x~ R3.0.x~
Table 9-9 Cables

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
