GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 9 - Page 9-17
703 Top Cable Assy 3 5252346
Front USB Cable, MIC
Cable
1. MIC Cable,
Connect one side
(Labe
l:MIC) to LP6 Front
USB Bracket and another
side (Label: J205) to PCB
Silk J205 of Backplane
Assy
2. Front USB Cable,
Connect one side (Label:
F_USB)
to LP6 Fr
ont USB
Bracket
and another
side
(Labe
l: J14) to Label J14 of
ARP Assy
1 1 Yes Yes Yes
704 ACPC Cable II 5168846
Connect one side(Label:
J3) to PCB Silk “J3” of LP6
Backplane and another
side(Label:CON2, T-FAN)
to Label CON2 and T-FAN
of Internal ACPC Con
Cable Assy 2
1 1 Yes Yes Yes
705 Printer Cable Assy 1 5177395
Connect one side to BW
Printer Power cable and
another side to External
Printer (short cable)
1 1 Yes Yes Yes
706 Printer Cable Assy 2 5168842
Connect one side to BW
Printer Power cable and
another side to External
Printer (long cable)
1 1 Yes Yes Yes
707 HDD/ODD Cable Set 5252342
EIDE Cable II, SATA Cable,
DVD Power Cable
1. EIDE Cable II,
Connect one side
(Labe
l:ODD)
to LP6 ODD
Assy and another side
(Labe
l: J204)
to PCB Silk
J20
4
of LP6 Backplane
As
sy
2. SATA Cable,
Connect one side to LP6
HDD Assy
and another side
to LP6 Backplane Assy
3. DVD Pow
e
r Cable,
Connect one side
(Labe
l:
ODD) to LP6 APS II
Assy and another side to
LP6 ODD Assy
1
1 Yes Yes Yes
708 APS II AC Power Cable 5252347
Connect one side
(Label:APS II) to Label APS
II of LP6 APS II Assy
and another side (Label:
CON3) to Label CON3 of
AC Out Cable
1 1 Yes Yes Yes
Item Part Name FRU Number Description Qty FRU R1.0.x R2.0.x~ R3.0.x~
Table 9-9 Cables
