GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Chapter 3 - Page 3-7

Section 3-3 Receiving and Unpacking the Equipment (cont’d)

4.) Remove the three PLASTIC JOINTs from the OUTER SLEEVE.

5.) Remove the OUTER SLEEVE.

Figure 3-5 Removing Plastic Joints and Sleeves

Plastic Joint

Outer Sleeve

Palette Assy
