11-38 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Inserting Wall motion scoring analysis containers
Two different containers must be inserted for the Wall motion
scoring analysis:
• A Wall motion scoring diagrams container (Cut planes or
Bull’s eyes)
• A Wall motion scoring table
Inserting Wall motion scoring diagrams container
1. Select the location where to insert the free text container (a
table cell or directly in the report template).
2. Select Insert, Wall motion analysis and select between
Cut planes and Bull’s eye.
The corresponding Wall motion score box is displayed.
Figure 11-23. The Wall motion score box (Cut planes)
3. Adjust the parameters and select OK:
The scoring diagrams are inserted in the report template
Inserting Wall motion scoring table container
1. Place the cursor right below the Wall motion scoring
diagrams container.
2. Select Insert, Wall motion analysis and select Score table
box.
The Score table box is displayed.
