Connectivity configuration
Vivid S70 / S60 – User Manual 12-49
BC092760-1EN 01
Refer to the Vivid S70 / S60 Reference manual for a
complete list of supported parameters.
• The following modes: 2D, M-mode, Color Flow, PW Doppler,
CW Doppler, 3D and TDI.
• Not Modified Simpson method or Bullet methods.
Refer to the Vivid S70 / S60 Reference manual for a
complete list of supported methods.
• Basic derivations (Average, Last, Min and Max), no
references between the derived measurements and the
ones they were made from.
• Wall Motion Scoring: individual segment scores only
according to 16-segment model, no graded Hypokinesis
(only Hypokinesis is used).
DICOM SR must be activated for each DICOM device.
1. Press Utility/Config on the control panel and log on as
administrator.
2. Select the Connectivity category and Dataflow subgroup.
The Dataflow sheet is displayed (see Figure 12-29).
3. Select the DICOM dataflow to configure in the Dataflow
pull-down menu.
4. Select a DICOM storage device and press Properties.
The Properties window for the selected DICOM storage
device is displayed.
Figure 12-34. DICOM SR Settings
5. Check the option Allow SR to enable DICOM SR.
The following additional options are available:
• Allow SR private data: include current exam data in a
private format within DICOM SR to retain
measurements and complete exam information when
recalling an exam from a DICOM environment. This is
especially important if EchoPAC Plug-in is used in the
