Configuration
ENG - Version 2.1 – P/N 04130.2 153
2. Select the settings.
Table 7-8 contains the possible values.
Field Setting Values
General Sweep speed 12.5 mm/s, 25 mm/s, 50 mm/s
P Display
Scale
Auto; 0 to 30; 0 to 60;
0 to 120; 0 to 180; 0 to 300
-10 to 10; -20 to 20;
-30 to 30; -40 to 40; -50 to 50
Auto Curve
Enabled,
disabled
7-8 Values for IBP monitoring
Depending on the measurement site (e.g. arterial, central venous, intracranial)
the printing area must be scaled accordingly.
If the check box "Auto Curve" is ticked, the IBP curve will be displayed on the
screen as soon as the IBP sensor is connected to the patient box and the
corresponding measuring channel is calibrated.
The function "Auto Curve" does not work for negative pressure values.
In the main menu, select "IBP" ► "Calib. P {measuring channel}" of the
respective pressure channel.
1. Calibration is performed automatically. In case the calibration cannot be
performed correctly, the alarm “IBP calibration error“ appears.
The IBP channel can be calibrated directly in the context menu of the pertaining
parameter field. After calibration of the channel, the IBP curve is displayed
automatically (Auto Curve).
