GS corpuls3 - Page 222

Maintenance and tests User Manual corpuls
3
210 ENG - Version 2.1 – P/N 04130.2
Functional
test
Description Measures by the user Correct result
ECG
monitoring
Function
check of the
ECG
monitoring
cable and the
complementar
y ECG
diagnostic
cable
 If no obvious damage to
the ECG monitoring cable
or the complementary ECG
diagnostic cable is visible,
a function check is not
necessary.
 It is, however
recommended to connect
them regularly to the ECG
cable tester corpuls
3
(P/N
04224), the testbox (P/N
04310), to an ECG
simulator or to a volunteer.
 If the heart rate or the ECG
are not displayed in a
parameter- or curve field, it
is possible that the
configuration has not been
set.
Assign the display to a
parameter- or curve field.
The ECG is displayed as
expected in the configured curve
fields.
Oximetry Function
check of
oximetry
measurement
 Attach oximetry sensor to a
finger.
 If the SpO
2
-, SpCO-, SpHb-
, SpMet value, the pulse
rate, the perfusion index or
the plethysmogram are not
displayed in a parameter or
curve field, they may be not
configured.
Select the display in a
parameter or curve field.
 The oximetry values are
displayed in one or more
parameter field.
 The pulse rate is displayed in
a parameter field (PP).
 The plethysmogram is
displayed in a curve field.
Capnometry Function
check of CO
2
measurement
 Connect a disinfected
airway adapter to the CO
2
sensors and attach the
connecting cable to the
patient box.
 Breathe in and out through
the adapter several times.
 If the CO
2
value,
respiratory rate or the
capnogram is not displayed
in a parameter or curve
field, they may be not
configured.
Select the parameter or
curve field in which the
value should be shown
 The CO
2
value is displayed in
a parameter field.
 The respiratory rate (RR) is
displayed in a parameter field.
 The capnogram is displayed in
a curve field.
