User Manual corpuls
3
Procedure in case of malfunctions
ENG - Version 2.1 – P/N 04130.2 239
Alarm message Priority Explanation/Measure
HW conflict [MODULE]
Low priority  The wireless connection authorisation (Pairing) has
failed.
 Due to different hardware versions the modules
used can only be used as compact device with an
ad-hoc connection.
 Contact sales and service partners, if necessary.
IBP (X) sensor loose
(X) sensor loose (P-
Box)
Medium priority  „X“ stands for an IBP sensor P1 to P4
 The sensor indicated is not correctly connected to
the transducer system or intermediate cable.
 The sensor is being calibrated.
 Check the respective sensor and secure again if
necessary.
IBP calibration error
Medium priority  The calibration of the invasive pressure channel has
failed.
 Repeat calibration.
IBP P1 cable loose
IBP P2 cable loose
IBP P3 cable loose
IBP P4 cable loose
Medium priority  The cable indicated is not connected to the patient
box while the device tries to calibrate the respective
pressure channel.
 Check the respective cable and reconnect if
necessary.
Insurance card reader
n. a.
Low priority  The insurance card reader could not be initialised.
 If the patient's condition is not critical, re-start the
corpuls
3
.
 If the alarm message persists, contact authorised
sales and service partners.
Invalid Oxi adhesive
sensor
Inv. adh. Oxi sen. (P-
Box)
Medium priority  The adhesive sensor is defective or has expired.
 The sensor LED's have to be aligned directly over
each other at the measuring site.
Invalid Oxi cable
Invalid Oxi cable (P-
Box)
Medium priority  A wrong intermediate cable is used.
 The intermediate cable has to be replaced by a
correct one.
Invalid Oxi sensor
Inval. Oxi sen. (P-Box)
Medium priority  A wrong sensor is used.
 The sensor has to be replaced by a correct one.
Invalid user settings
Inval. settings (P-Box)
Medium priority  The loaded settings do not correspond to the
imported settings. The corpuls
3
uses factory
settings.
Low confidence (X)
Low conf. (X) (P-Box)
Low priority  "X" stands for the vital parameters PI, PP, SpCO,
SpHb, SpMet or SpO
2
.
 PI measurement is not possible.
 Make sure that the correct sensor is used.
 Check if the sensor is functional.
 If necessary, replace sensor.
