GS corpuls3 - Page 305

User Manual corpuls
3
Appendix
ENG - Version 2.1 – P/N 04130.2 293
Biphasic Defibrillator
Description/explanation
Energy levels for manual and
AED defibrillation with shock
paddles or corPatch easy
electrodes and shock spoons
 2, 3, 4, 5, 10, 15 to 200 J for adults
 2, 3, 4, 5, 10, 15 to 100 J for children with
corPatch easy electrodes (Neonates)
 2, 3, 4, 5, 10, 15 to 50 J with shock spoons (only in manual
defibrillation mode)
 Fine adjustment of energy level in steps of 5 Joules
(delivered energy to 50 Ω)
 Interim values can be set with jog-dial
Direct selection of energy levels via softkeys
 Adults: 50, 100, 150, and 200 Joules
 Children: 25, 50, 75 and 100 Joules
Number of shocks per battery
load (fully charged)
Approx. 200 shocks with 200 J
(with the battery of the defibrillator alone)
Manual defibrillation:
Charging time to max. energy
(with a fully charged battery)
Less than 5 sec.
Manual defibrillation:
Charging time to max. energy
after release of 15 shocks
Less than 5 sec. (no difference to fully charged battery)
Manual defibrillation:
Charging time to max. energy
after switch on of corpuls
3
Less than 25 sec.
AED mode:
Max. time from start of ECG
analysis to ‘
Ready for shock
‘
Less than 12 sec.
AED mode:
Max. time from start of ECG
analysis to ‘Ready for shock’
after release of 15 shocks with
max. energy
Less than 12 sec. (no difference to fully charged battery)
AED mode:
Max. time from switch on to
‘
Ready for shock
’
Less than 30 sec.
Pulse waveform Biphasic,
positive rectangular waveform 4 msec. (90 % energy)
negative rectangular waveform 3 msec. (10 % energy)
Patient impedance range within
which a shock can be delivered
corPatch easy electrodes > 15 Ω to ≤ 600 Ω
Shock paddles > 15 Ω to ≤ 600 Ω
Shock spoons > 0 Ω to ≤ 600 Ω
Accuracy of delivered energy on
an impedance of 50 Ω
Better than ± 10 %
Table A
-20 Biphasic defibrillator
