Appendix User Manual corpuls
3
294 ENG - Version 2.1 – P/N 04130.2
Non-invasive Pacer
Description/explanation
Output Insulated application part Type BF, insulation voltage > 5 kV
Pacing frequency  30/min. to 150/min
(adjustable in steps of 5/min.)
 in OVERDRIVE mode 30/min. to 300/min.
(adjustable in steps of 1/min.)
Intensity of pacing current 10 to 150 mA
(0-10 mA, then adjustable in increments of 5 mA)
Impulse duration 22.5 msec. (rectangular current impulse)
Operating modes FIX, DEMAND, OVERDRIVE modes
OVERDRIVE frequency
Heart rate of the patient minus 10/min. and if necessary
rounded down to the next smaller number divisible by 5.
Example: Heart rate = 179/min.,
Overdrive frequency = 165/min.
Table A
-21 Non-invasive pacer
Impulse suppression according to IEC 60601-2-27
Amplitude
Rise time
2.5 mV 5.0 mV 8.3 mV 16.7 mV
0.010 µs 38 µs 16 µs 9 µs 4 µs
0.050 µs 38 µs 16 µs 9 µs 4 µs
0.100 µs 38 µs 16 µs 9 µs 4 µs
0.500 µs 38 µs 15 µs 8 µs 3 µs
1.000 µs 38 µs 15 µs 8 µs 3 µs
5.000 µs 35 µs 11 µs 4 µs 0 µs
10.000 µs 31 µs 7 µs 0 µs 0 µs
50.000 µs 4 µs 0 µs 0 µs 0 µs
100.000 µs 0 µs 0 µs 0 µs 0 µs
Table A
-22 Impulse suppression according to IEC 60601-2-27
The voltages for impulse amplitudes itemised in Table A-22 refer to the internal patient voltage. The
measured impulse widths are rectangular impulses.
CPR Feedback
Description/Explanation
Function principle Acceleration sensor
Displayed parameters  Combined curve for display of compression depth and
compression frequency
 CPR rate (compression rate)
