OPERATION
105
2. Press F2 (Width). The Width
parameter will be highlighted
in the parameter window.
3. There are two ways to set its
value :
a,Use the arrow keys and
scroll wheel
b, number pad to enter the
Duty range.

/


 




/


 



Press F2~F5 choose the unit
range.
E

~
E

Pulse Width Range
≧20ns(limited by the
current frequency setting)
4. To set parameter
Load/Frequency/Amplitude/DC
Offset/Phase, please see page 109 - 113.
