MFG-2000 Series User Manual
292
width as noted below:
Leading/Trailing Edge Time ≤ 0.625 × Pulse Width
Syntax
SOURCEPULSE:PULSe:TRANsition:LEADing
{<seconds>|MINimum|MAXimum}
Example
SOURCEPULSE:PULS:TRANsition:LEADing MAX
Sets the pulse transition trailing to the maximum
allowed.
Query Syntax
SOURCEPULSE:PULSe:TRANsition:LEADing?
[MINimum|MAXimum]
Return Parameter
<seconds>
≧10ns(limited by the
current frequency and
pulse width settings)
Example
SOURCEPULSE:PULS:TRANsition:LEADing?
+8.0000E-08
The pulse transition trailing is set to 80
nanoseconds.
SOURCEPULSE:PULSe:TRANsition
:TRAIling
Source Specific
Command
Description
Sets or queries the pulse trailing edge time. The
default rise time is 10ns. The leading and trailing
edge time can be different.
Note
The trailing edge time is limited by the pulse
width as noted below:
Leading/Trailing Edge Time ≤ 0.625 × Pulse Width
Syntax
SOURCEPULSE:PULSe:TRANsition:TRAIling
{<seconds>|MINimum|MAXimum}
Example
SOURCEPULSE:PULS:TRANsition:TRAIling MAX
Sets the pulse transition trailing to the maximum
allowed.
