GW Instek MFG-2000 Series - Saving a Waveform to USB Memory

ARBITRARY WAVEFORMS
241
10. Select a memory file using the
scroll wheel.
ARB0~ARB9
11. Press F1 (Select) to save the
selected memory file.


12. Press Return to return to the
previous menu.

Below the file ARB1 is selected using the scroll
wheel.
Saving a Waveform to USB Memory
Panel Operation
1. Press the ARB key.

2. Press F4 (Save).
av

3. Press F1 (Start).
a

