MEMory:STATe:DELete ALL

Instrument

Command

Description

Delete memory from all memory locations, 0~9.

Syntax

MEMory:STATe:DELete ALL

Example

MEM:STAT:DEL ALL

Deletes all the instrument states from memory

locations 0~9.
