MFG-2000 Series User Manual
40
9. Press the output key.
PM Modulation
Example: PM modulation. 800Hz sinusoidal carrier wave. 15 kHz
modulating sine wave. 180˚ phase deviation. Internal Source.
Output:



1. Press Waveform and
select Sine (F1).


2. Press the MOD key
and select PM (F4).


Input: N/A
3. Press the Freq/Rate
key, followed by 8 + 0
+ 0 + Hz (F4).
Q
z
4. Press the MOD key,
select PM (F4), Shape
(F4), Sine (F1).

 ha

5. Press MOD, then PM
(F4), PM Freq (F3).

 q
6. Press 1 + 5 + kHz
(F3).
kz
7. Press MOD, PM (F4),
PM Dev (F5).

 haDv
8. Press 5 + 0 + Degree
(F1).
Dg
9. Press MOD, PM (F4),
Source (F1), INT (F1).

 

