MODULATION
181
7. Use the arrow keys and scroll
wheel or number pad to enter
the frequency.

/


 



8. Press F1~F5 to select the
frequency unit.
z

~
z

Range
Frequency
Sine wave
1μHz~320MH(max)
Square wave
1μHz~25MHz(max)
Pulse wave
1μHz~25MHz(max)
Ramp wave
1μHz~1MHz
Default
550Hz
Note
The marker frequency must be set to a value
between the start and stop frequencies. If no value
is set, the marker frequency is set to the average of
the start and stop frequencies.
Marker mode will override SYNC mode settings
when sweep mode is active.
Sweep Trigger Source
In sweep mode the function generator will sweep each time a
trigger signal is received. After a sweep output has completed, the
function generator outputs the start frequency and waits for a
trigger signal before completing the sweep. The default trigger
source is internal.
Panel Operation
1. Press the SWEEP key.

2. Press F1 (Source).


