APPENDIX
383
APPENDIX
The specifications apply when the function
generator is powered on for at least 30 minutes
under +18°C~+28°C.
Specifications
MFG-2000 series specific functions
CH1
CH2
25MHz
Pulse
Generator
RF
Generator
(function
with ARB)
Power
Amplifier
Modulation
/Sweep/Burst/Fr
equency.Counter
Function With
200MSa/sARB
Function With
200MSa/sARB
MFG-2110
10MHZ
MFG-2120
20MHZ
MFG-2120MA
20MHZ
MFG-2130M
30MHZ
MFG-2160MF
60MHZ
160MHZ
MFG-2160MR
60MHZ
320MHZ
MFG-2230M
30MHZ
30MHZ
MFG-2260M
60MHZ
60MHZ
MFG-2260MFA
60MHZ
60MHZ
160MHZ
MFG-2260MRA
60MHZ
60MHZ
320MHZ
CH1/ CH2
Waveforms
Standard
Sine,Square,Ramp,Pulse,Noise
Arbitrary
Functions
ARB function
Built-in
Built-in Arbitrary waveforms, please see page 395.
Absatan,Abssine,Abssinehalf,Ampalt,Attalt,Diric.even,Diric.odd,
Gauspuls,Havercosine,Haversin,N_pulse,Negramp,Rectpuls,Ro
undhalf,Sawtoot,Sinetra,Sinever,Stair_down,Stair_ud,Stair_up,St
epresp,Traperia,Tripuls,Airy,Bessel,Beta,Gamma,Legendre,Neem
ann,Arccos,Arccot,Arccsc,Arcsec,Arcsin,Arcsinh,Arctan,Arctanh,
Cosh,Cot,Csc,Dlorentz,expofall,exporise,gauss,ln,lorentz,Sec,Sec
h,Sinc,Sinh,Sqrt,Tan,Tanh,Xsquare,Barthannwin,Bartlett,Blackma
n,Bohmanwin,Chebyshev,Flatttopwin,Hamming,Hann,Hanning,
Kaiser,Triang,Tukeywin etc.
Sample Rate
200 MSa/s
Repetition Rate
100MHz
Waveform Length
16k points
Amplitude Resolution
14 bits
Non-Volatile Memory
10sets 16k points(1)
User-defined output section
From point 2~16384 (optional)
