GW Instek MFG-2000 Series User Manual

REMOTE INTERFACE
357
PHASE
The phase command remotely controls the phase and channel
synchronization.
SOURCE[1|2|pulse]:PHASe
Instrument
Command
Description
Sets the phase.
Syntax
SOURce[1|2|pulse]:PHASe
{<phase>|<MIN>|<MAX>}
Parameter
phase
-180~180
min
Sets the phase to the minimum
value.
max
Sets the phase to the maxium
value.
Example
SOURce1:PHASe 25
Sets the phase of channel 1 to 25°.
Query Syntax
SOURce[1|2|pulse]:PHASe? {MAX|MIN}
Return Parameter
<NRf>
Returns the current phase in degrees.
Example
SOURce1:PHASe?
+2.500E+01
Returns the phase of channel 1 as 25°.
SOURce[1|2|pulse]:PHASe:SYNChronize
Instrument
Command
Description
Sychronizes the phase of channel 1 and channel 2.
Syntax
SOURce[1|2|pulse]:PHASe:SYNChronize
Example
SOURce1:PHASe:SYNChronize
Synchronizes the phase of channel 1
