GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
130
ASK Rate
The ASK rate setting determines the rate at which the amplitude
will switch from the carrier amplitude and the modulation
amplitude.
Panel Operation
1. Select MOD.

2. Press F2 (ASK).
K

3. Press F3 (ASK Rate).
Ka

4. The ASK Rate parameter will become
highlighted in the Waveform Display area.
5. Use the selector keys and
scroll wheel or number pad
to enter the ASK frequency
rate.

/


 



6. Press F1 ~ F4 to select the
frequency unit.
z

~
kz

Range
ASK frequency rate
2mHz~1MHz
Default
100Hz
