GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
340
Example
SOUR1:BURS:MODE?
TRIG
The current burst mode is triggered.
SOURce[1|2|3]:BURSt:NCYCles
Source Specific
Command
Description
Sets or queries the number of cycles (burst count)
in triggered burst mode. The default number of
cycles is 1. The burst count is ignored in gated
mode.
Note
If the trigger source is set to immediate, the
product of the burst period and waveform
frequency must be greater than the burst count:
Burst Period X Waveform frequency > burst count
If the burst count is too large, the burst period will
automatically be increased and a “Settings
conflict” error will be generated.
Only sine and square waves are allowed infinite
burst above 25 MHz.
Syntax
SOURce[1|2|3]:BURSt:NCYCles{< # cycles>
|INFinity|MINimum |MAXimum}
Parameter
<# cycles>
1~1,000,000 cycles.
INFinity
Sets the number to continuous.
MINimum
Sets the number to minimum allowed.
MAXimum
Sets the number to maximum allowed.
Example
SOUR1:BURS:NCYCl INF
Sets the number of burst cycles to continuous
(infinite).
Query Syntax
SOURce[1|2|3]:BURSt:NCYCles?
[MINimum|MAXimum]
Return Parameter
<NR3>
Returns the number of cycles.
INF
INF is returned if the number of cycles
is continuous.
