MODULATION
155
Phase Shift Keying(PSK)
PSK modulation alternates the output between two preset phase
values (carrier phase and modulation phase)
Only one mode of modulation can be enabled at any one time. If
PSK is enabled, any other modulation mode will be disabled.
Likewise, burst and sweep modes cannot be used with PSK and will
be disabled when PSK is enabled. PSK modulation is only for RF
Channel.
Select PSK Modulation
When using the PSK modulatin mode, the output waveform uses
the default carrier frequency, amplitude and offset voltage.
Panel Operation
1. Press the MOD key.

2. Press F6 (PSK).
K

