DUAL CHANNEL OPERATION

217

Sync Int (For 22XX only)

Background

Synchronizes the phase of both channelsand sets

the phase to 0º.

Panel Operation

1. Press the UTIL key.



2. Press F5 (Dual Ch).

Dah



3. Press F4 (Sync Int).


