GW Instek MFG-2000 Series User Manual

REMOTE INTERFACE
313
Syntax
SOURce[1|2|3|3RF]:PM:INTernal:FREQuency
{<frequency>|MINimum|MAXimum}
Parameter
<frequency>
2 mHz~ 20 kHz
Example
SOUR1:PM:INT:FREQ MAX
Sets the frequency to the maximum value.
Query Syntax
SOURce[1|2|3|3RF]:PM:INTernal:FREQuency?
Return Parameter
<NR3>
Returns the frequency in
Hz.
Example
SOUR1:PM:INT:FREQ?
+2.0000000E+04
Returns the modulating frequency. (20kHz)
SOURce[1|2|3|3RF]:PM:DEViation
Source Specific
Command
Description
Sets or queries the phase deviation of the
modulating waveform from the carrier waveform.
The default phase deviation is 180°.
Note
For external sources, the phase deviation is
controlled by the ±5V MOD Input terminal on the
rear panel. If the phase deviation is set to 180
degrees, then +5V represents a deviation of 180
degrees. A lower input voltage will decrease the
set phase deviation.
The RF channel supports only the internal
modulation mode.
Syntax
SOURce[1|2|3|3RF]:PM:DEViation {<
phase>|minimum |maximum}
Parameter
<percent>
0°~360°
Example
SOUR1:PM:DEViation +3.0000E+01
Sets the deviation to 30°.
Query Syntax
SOURce[1|2|3|3RF]:PM:DEViation?
Return Parameter
<NR3>
Returns the deviation .
