Setting the Phase
Panel Operation
1. Press the CH1 or CH2 or
CH1/CH2 key.
21XX
22XX

Parameter
settings
2. Phase setting. Select the corresponding channel
and then press F5(Phase).
3. There are two ways to set its
value :
a,Use the arrow keys and scroll
wheel
b, number pad to enter the Duty
range.

/


 




/


 



