GW Instek MFG-2000 Series User Manual

QUICK REFERENCE
45
Sweep
Example: Frequency Sweep. Start Frequency 10mHz, Stop frequency
1MHz. Log sweep, 1 second sweep, Marker Frequency 550 Hz,
Manual Trigger.
Output:

     
     
     
    
   
     
  

     

     
     
     
1. Press Sweep, Start
(F3).

a
2. Press 1 + 0 + mHz
(F2).

z

3. Press Sweep, Stop
(F4).


Input: N/A
4. Press 1 + MHz (F5).

z
5. Press Sweep, Type
(F2), Log (F2).

 g
6. Press Sweep, SWP
Time (F5).
7. Press 1 + SEC (F2).

E
8. Press Sweep, More
(F6), Marker (F3),
ON/OFF (F2), Freq
(F1).

 ak
OO q
9. Press 5 + 5 + 0 + Hz
(F3).


z

10. Press the Output key.
