GW Instek MFG-2000 Series User Manual

REMOTE INTERFACE
279
Syntax
SOURce[1|2|3|3RF]:APPLy:USER [<frequency>
[,<amplitude> [,<offset>] ]]
Parameter
<frequency>
1μHz~100MHz
<amplitude>
0~10V (50Ω)
<offset>
±5 Vpk ac +dc (50Ω)
Example
SOUR1:APPL:USER 1KHZ,5.0,1.0
SOURce[1|2|3|3RF]:APPLy?
Source Specific
Command
Description
Outputs a string with the current settings.
Note
The string can be passed back appended to the
Apply Command.
Syntax
SOURce[1|2|3|3RF|pulse]:APPLy?
Return Parameter
<string>
Function, frequency,
amplitude, offset
Example
SOUR1:APPL?
SIN +5.0000000000000E+03,+3.0000E+00,-2.50E+00
Returns a string with the current function and
parameters, Sine, 5kHz, 3 Vpp, -2.5V offset.
