GW Instek MFG-2000 Series User Manual

QUICK REFERENCE
47
Burst
Example: Burst Mode, N-Cycle (Internally triggered), 1kHz burst
frequency, Burst count = 5, 10 ms Burst period, 0˚ burst phase,
Internal trigger, 10 us delay, rising edge trigger out
Output:

     
     
     
    
   
     
  

     

     
     
     
1. Press FREQ/Rate 1
kHz (F5).

kz
Q
2. Press Burst, N Cycle
(F1), Cycles (F1).

 
Input: N/A
3. Press 5 + Cyc (F5).


4. Press Burst, N Cycle
(F1), Period (F4).

 d
5. Press 1 +0 + msec
(F2).

E

6. Press Burst, N Cycle
(F1), Phase (F3).

 ha
7. Press 0 + Degree (F5).

Dg
8. Press Burst, N Cycle
(F1), TRIG set (F5),
INT (F1).

 g

9. Press Burst, N Cycle
(F1), TRIG set (F5),
Delay (F4).

 g
Da
10. Press 1 + 0 + uSEC
(F5).

E

