MFG-2000 Series User Manual
352
Parameter
<addrress1>
Address of data point1:
0~16384
<data1>
Value data2: ±8192
<address2>
Address of data point2:
0~16384
<data2>
Value data2: ± 8192
Example
SOUR1:ARB:EDIT:LINE 40, 50, 100, 50
Creates a line on the arbitrary waveform at 40,50 to
100,50.
SOURce[1|2|3]:ARB:EDIT:PROTect
Source Specific
Command
Description
Protects a segment of the arbitrary waveform from
deletion or editing.
Syntax
SOURce[1|2|3]:ARB:EDIT:PROTect
[<STARt>[,<LENGth>]
Parameter
<STARt>
Start address: 0~16384
<LENGth>
0 ~ 16384
Example
SOUR1:ARB:EDIT:PROT 40, 50
Protects a segment of the waveform from address
40 for 50 data points.
SOURce[1|2|3]:ARB:EDIT:PROTect:ALL
Source Specific
Command
Description
Protects the arbitrary waveform currently in non-
volatile memory/currently being output.
Syntax
SOURce[1|2|3]:ARB:EDIT:PROTect:ALL
Example
SOUR1:ARB:EDIT:PROT:ALL
SOURce[1|2|3]:ARB:EDIT:UNProtect
Source Specific
Command
Description
Uprotects the arbitrary waveform currently in non-
volatile memory/currently being output.
