OPERATION

Triangle Waveform

Panel Operation

1. Press the Waveform key.



2. Press F3 (Triangle) to create

a triangle waveform.

ag



Parameter

settings

3. To set the parameter

Load/Frequency/Amplitude/DC Offset/

Phase, please refert to page 83 - 89.

Pulse Waveform

Panel Operation

1. Press the Waveform key.


