GW Instek MFG-2000 Series - Clear the Waveform

ARBITRARY WAVEFORMS
233
Clear the Waveform
Panel Operation
1. Press the ARB key.

2. Press F2 (Edit).
Ed

3. Press F4 (Clear).
a

4. Press F1 (Start).
a

5. The Clear From properties will become
highlighted in red.
6. Use the arrow keys and scroll
wheel or number pad to enter
the Clear From address.

/


 



7. Press F5 (Enter) to save the
settings.
E

8. Press Return to return to the
previous menu.

9. Repeat steps 4~8 for Length
(F2).
gh

10. Press F3 (Done) to clear the
selected section of the
arbitrary waveform.
D

