REMOTE INTERFACE
351
SOURce[1|2|3]:ARB:EDIT:DELete:ALL
Source Specific
Command
Description
Deletes all user-defined waveforms from non-
volatile memory and the current waveform in
volatile memory.
Note
A waveform cannot be deleted when output.
Syntax
SOURce[1|2|3]:ARB:EDIT:DELete:ALL
Example
SOUR1:ARB:EDIT:DEL:ALL
Deletes all user waveforms from memory.
SOURce[1|2|3]:ARB:EDIT:POINt
Source Specific
Command
Description
Edit a point on the arbitrary waveform.
Note
A waveform/waveform segment cannot be
deleted when output.
Syntax
SOURce[1|2|3]:ARB:EDIT:POINt [<address> [, <data>]]
Parameter
<address>
Address of data point:
0~16384
<data>
Value data: ± 8192
Example
SOUR1:ARB:EDIT:POIN 1000, 511
Creates a point on the arbitrary waveform at
address 1000 with the highest amplitude.
SOURce[1|2|3]:ARB:EDIT:LINE
Source Specific
Command
Description
Edit a line on the arbitrary waveform. The line is
created with a starting address and data point and
a finishing address and data point.
Note
A waveform/waveform segment cannot be
deleted when output.
Syntax
SOURce[1|2|3]:ARB:EDIT:LINE
[<address1>[,<data>[,<address2>[,<data2>]]]]
