Load a Waveform from USB
Panel Operation
1. Press the ARB key.

2. Press F5 (Load).
ad

3. Press F2 (USB).
B

4. Use the scroll wheel to choose
a file name.
5. Press F1 (Select) to select the
file to load.


6. Press F3 (To) to choose the
starting point for the loaded
waveform.


7. The Load To property will become highlighted
in red.
