ARBITRARY WAVEFORMS
245
6. Press F3 (To) to choose the
starting point for the loaded
waveform.


7. The Load To parameter will become
highlighted in red.
8. Use the selector keys and
scroll wheel or number pad
to enter the starting point.

/


 



9. Press F5(Enter) to confirm the
start point.
E

10. Press F6 (Return) to return to
the previous menu.


11. Press F5(Done).
D

Below the file ARB1 is selected using the scroll
wheel loaded to position 0.
