REMOTE INTERFACE
347
SOURce[1|2]:BURSt:OUTPut:TRIGger
Source Specific
Command
Description
Sets or queries the trigger output signal on or off.
By default the signal is disabled. When enabled, a
TTL compatible square wave is output. This
function applies to sweep as well as burst mode.
Syntax
SOURce[1|2]:BURSt:OUTPut:TRIGger {OFF|ON}
Parameter
OFF
Turns the output off.
ON
Turns the output on.
Example
SOURce1:BURSt:OUTPut:TRIGger ON
Turns the output on.
Query Syntax
SOURce[1|2]:BURSt:OUTPut:TRIGger?
Return Parameter
0
Disabled
1
Enabled
Query Example
SOURce1:BURSt:OUTPut:TRIG?
1
The trigger output is enabled.
Arbitrary Waveform Commands
Arbitrary Waveform Overview
Use the steps below to output an arbitrary waveform over the
remote interface.
Output Arbitrary
Waveform
Select Waveform
1. Use the SOURce[1|2|3]:FUNCtion USER
command to output the arbitrary waveform
currently selected in memory.
