GW Instek MFG-2000 Series - ASK Source

MODULATION
131
ASK Source
The function generator will accept an internal or external source for
ASK modulation. The default source is internal. When Internal
Source is selected, the ASK Rate setting will set the frequency rate.
Panel Operation
1. Press the MOD key.

2. Press F2 (ASK).
K

3. Press F1 (Source).


4. Press F1 (Internal) or F2
(External) to select the ASK
source.


~
EX

5. Press Return to return the
previous menu.

