GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
384
User-defined output marker
section
From point 2 ~ 16384(optional)
Output mode
1~1000000 cycles or infinite mode
Frequency
Characteristics
Range
Sine 60MHz(max)
Square 25MHz(max)
Triangle, Ramp 1MHz
Resolution
1μHz
Accuracy Stability
±20 ppm
Aging
±1 ppm, per 1 year
Tolerance
≤1μHz
Output
Characteristics(2)
Amplitude Range
1mVpp to 10 Vpp (into 50Ω)
2mVpp to 20 Vpp (open-circuit)
Accuracy
±2% of setting ±1 mVpp
(at 1 kHz/into 50Ω without DC
offset))
Resolution
0.1mV or 4 digits
Flatness
± 1% (0.1dB) ≦1MHz
± 3% (0.3dB) ≦50 MHz
± 16% (1.5dB) ≦60MHz(6)
(sinewave relative to 1 kHz/into
50Ω)
Units
Vpp, Vrms, dBm
Offset
Range
±5 Vpk ac +dc (into 50Ω)
±10Vpk ac +dc (Open circuit)
Accuracy
±(1% of setting + 5mV+ 0.5% of
amplitude)
Waveform
Output
Impedance
50Ω typical (fixed)
>10MΩ (output disabled)
Protection
Short-circuit protected
Overload relay automatically disables
main output
Ground Isolation
42Vpk max
Sync Output
Range
TTL-compatible into>1kΩ

GW Instek MFG-2000 Series Specifications

General

Brand	GW Instek
Model	MFG-2000 Series
Category	Inverter
Language	English
