GW Instek MFG-2000 Series User Manual

APPENDIX
385
Impedance
50Ω standard
Ground Isolation
42Vpk max
Sine wave
Characteristics(3)
Harmonic
distortion
–60 dBc <200kHz,
Ampl>0.1 Vpp
–55 dBc 200kHz～1 MHz,
Ampl>0.1 Vpp
–45 dBc 1MHz～10 MHz, Ampl＞
0.1Vpp
–35 dBc 10MHz～30MHz, Ampl＞
0.1Vpp
–27 dBc 30MHz～60MHz, Ampl＞
0.1Vpp
Total harmonic distortion
< 0.1% (Ampl>1Vpp)
DC~100 kHz
Square wave
Characteristics
Rise/Fall Time
<15ns
Overshoot
<5%
Asymmetry
1% of period +5 ns
Variable duty Cycle
0.01% to 99.99%(limited by the
current frequency setting)
Jitter
20ppm+500ps(4)
Ramp
Characteristics
Linearity
< 0.1% of peak output
Variable Symmetry
0% to 100%
Pulse
Characteristics
Frequency
1uHz~25MHz
Pulse Width
≧20nS(limited by the current
frequency setting)
Variable duty Cycle
0.01%~99.99%(limited by the current
frequency setting)
Overshoot
<5%
Jitter
20ppm+500ps(4)
Pulse
Generator
Amplitude
1mVpp to 2.5 Vpp (into 50Ω)
2mVpp to 5 Vpp (open-circuit)
