REMOTE INTERFACE

293

Query Syntax

SOURCEPULSE:PULSe:TRANsition:TRAIling?

[MINimum|MAXimum]

Return Parameter

≧10ns(limited by the

current frequency and

pulse width settings)

Example

SOURCEPULSE:PULS:TRANsition:TRAIling?

+8.0000E-08

The pulse transition trailing is set to 80

nanoseconds.
