3. There are two ways to set its
value :
a,Use the arrow keys and
scroll wheel
b, number pad to enter the
Duty range.

/


 




/


 



Press F1~F3 to choose the
unit range.
E

~

4. Repeat the above steps for the opposite edge
time.
Minimum
Tariling Edge
time Range
≧10nS(limited by the current
frequency and pulse width
settings)
Edge time
Considerations
Trailing Edge Time ≤ 0.625 ×
Pulse Width
5. To set parameter
Load/Frequency/Amplitude/DC
Offset/Phase, please see page 109 - 113.
