GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
282
Sine, Square
1μHz~320MHz/25MHz
Ramp
1μHz~1MHz
Pulse
1μHz~25MHz
Noise
Not applicable
User
1μHz~100MHz
If the function mode is changed and the current
frequency setting is not supported by the new
mode, the frequency setting will be altered to next
highest value.
The duty cycle of square waveforms depends on
the frequency settings.
0.01% to 99.99%
If the frequency is changed and the set duty cycle
cannot support the new frequency, the highest
duty cycle available at that frequency will be used.
A “settings conflict” error will result from the
above scenario.
Syntax
SOURce[1|2|3|3RF|pulse]:FREQuency
{<frequency>|MINimum|MAXimum}
Example
SOUR1:FREQ MAX
Sets the frequency to the maximum for the current
mode.
Query Syntax
SOURce[1|2|3|3RF|pulse]:FREQuency?
Return Parameter
<NR3>
Returns the frequency for
the current mode.
Example
SOUR1:FREQ? MAX
+6.0000000000000E+07+1.0000000000000E+03
The maximum frequency that can be set for the
current function is 60MHz.
