GW Instek MFG-2000 Series User Manual

MFG-2000 Series User Manual
306
The carrier frequency must be greater than or
equal to the peak deviation frequency. The sum of
the deviation and carrier frequency must not
exceed the maximum frequency for a specific
carrier shape. If an out of range deviation is set for
any of the above conditions, the deviation will be
automatically adjusted to the maximum value
allowed and an “out of range” error will be
generated.
For square wave carrier waveforms, the deviation
may cause the duty cycle frequency boundary to
be exceeded. In these conditions the duty cycle will
be adjusted to the maximum allowed and a
“settings conflict” error will be generated.
Syntax
SOURce[1|2|3|3RF]:FM:DEViation {<peak deviation in
Hz>|MINimum|MAXimum}
Parameter
<peak deviation in Hz>
DC to Max Frequency
Example
SOUR1:FM:DEV MAX
Sets the frequency deviation to the maximum
value allowed.
Query Syntax
SOURce[1|2|3|3RF]:FM:DEViation?
[MINimum|MAXimum]
Return Parameter
<NR3>
Returns the frequency
deviation in Hz.
Example
SOURce[1|2|3|3RF]:FM:DEViation? MAX
+1.0000E+01
Returns the maximum frequency deviation
allowed.
