Inserting and Removing a USB ash drive
8.1 Inserting and Removing a USB ash drive
Inserting a USB ash drive
Insert the USB ash drive into the USB receptacle on the front of
the instrument.
• Do not insert a USB ash drive that is not Mass Storage Class compatible.
• Not all commercially available USB ash drives are compatible.
• If a USB ash drive is not recognized, try using another USB ash drive.
Removing a USB ash drive
Check that the USB ash drive is not being accessed (saving, read-
ing, etc.) by the instrument, and then remove it.
No remove operation needs to be performed on the instrument.
Screen Display when Using USB
When a USB ash drive has been recognized properly, the USB ash drive icon is displayed at the
top of the measurement screen.
The icon is red while the USB ash drive is being accessed.
(Blue)
When the instrument
recognizes the USB
ash drive
(Red)
When USB is being ac-
cessed
