152
Saving Measurement Data
To specify the save folder
This section describes how to set the desired folder as the data save destination.
Screen display method (For more information, see p. 29.):
(Measurement screen) FILE key>(FILE screen) SET tab
1
Insert the USB ash drive into the front
USB connector (p. 138).
2
Touch the SAVE TO... key.
3
Touch the MANUAL key.
AUTO Automatically creates a folder
named based on the save date
and saves data in that folder.
MANUAL Allows you to specify any folder
and then save the data.
4
Select the folder in which you wish to
save data with the  keys and then
touch the SET key.
Touch to cancel the conguration process. (The
dialog box will be closed.)
1
2
5
Touch the EXIT key.
Displays the measurement screen.
• The following folders can be specied:
• The root
*
directory of the USB ash drive
• The folder name is all single-byte characters (A folder name containing Japanese or other double-byte
characters cannot be specied.)
• The folder name is no more than 12 characters
• If the folder specied as the save destination is deleted, a folder of the same name will be created when
saving data.
*: “Root” refers to the uppermost level on the USB ash drive.
Removable disk
Root folder
