Hioki IM3536 - X84; Measurement and Data Acquisition Timing

65
Setting Measurement Conditions (basic settings)
Measurement and data acquisition timing
Measurement and data acquisition timing varies with the following settings:
Trigger synchronous output (p. 64), Trigger delay (p. 63), Trigger synchronous delay (p. 64),
DC delay (p. 61), Adjustment delay (p. 62)
When the trigger synchronization function is on
Trigger
synchronous
delay
Data acquisition
AC measurement
(trigger synchronization on)
DC
delay
Adjustment
delay
Data
acquisition
Data
acquisition
DC measurement
(trigger synchronization on)
(DC adjustment on）
Trigger
signal
DC measurement
(trigger synchronization on)
(DC adjustment off)
DC
delay
Data
acquisition
Trigger delay
Trigger delay
Trigger delay
DC measurement
after AC measurement
(trigger synchronization on)
(DC adjustment on）
DC measurement
after AC measurement
(trigger synchronization on)
(DC adjustment off）
Data acquisition
Switching time
(3.5 ms)
Data
acquisition
Adjustment
delay
Trigger
synchronous
delay
Trigger delay
Data
acquisition
Switching time
(3.5 ms)
DC
delay
Data
acquisition
Trigger delay
Switching time
1.5 ms
Switching time
1.5 ms
DC
delay
Data
acquisition
Switching time
0.5 ms
Trigger
synchronous
delay
Trigger
synchronous
delay
Trigger
synchronous
delay
3
Performing Measurements in LCR Mode
