External I/O Settings
9.4 External I/O Settings
The following settings govern EXT I/O. They can be set on the instrument and with communications
commands.
Setting the external trigger
You can control (start and stop) recording by inputting a specic
signal from an external device to the instrument.
Setting on the instrument: See p. 62.
Setting with a communications command:
See LCR application dikc - Communications command (
:TRIGger
).
Setting the Hi Z reject function
You can output a measurement terminal contact error when the
measurement results exceed a set judgment standard during
2-terminal measurement.
Setting on the instrument: See p. 84.
Setting with a communications command:
See LCR application dikc - Communications command "Hi Z
refect function".
Setting the delay time from judg-
ment results output to EO
M
―――
output
You can set the delay time from output of comparator and BIN
judgment results from EXT I/O to EOM
―――
output.
Setting on the instrument: See p. 181.
Setting with a communications command:
See LCR application dikc - Communications command
(
:IO:OUTPut:DELay
).
Setting reset of judgment results
You can reset comparator and BIN judgment results at the same
time as the measurement start signal.
Setting on the instrument: See p. 181.
See LCR application dikc - Communications command
(
:IO:RESult:RESet
).
Enabling trigger input for during
measurement
Whether to enable or disable trigger input from the EXT I/O
during measurement (during EOM
―――
(HI)) can be selected on the
instrument or by a communication command.
Setting on the instrument: See p. 182.
See LCR application dikc - Communications command
(
:IO:TRIGger:ENABle
).
Setting valid edge of trigger input
Either the rising edge or falling edge can be selected as the valid
edge of trigger input from the EXT I/O.
Setting on the instrument: See p. 182.
See LCR application dikc - Communications command
(
:IO:TRIGger:EDGe
).
Setting the EOM
―――
output method
and output time
You can set the output method for the EOM
―――
measurement com-
plete signal. You can also set the time for which EOM
―――
is held in the
LO state before the EOM
―――
measurement complete signal is output.
Setting on the instrument: See p. 183.
See LCR application dikc - Communications command
(
IO:EOM:MODE
).
Outputting measured values
(Switching to BCD mode)
During LCR mode operation, you can switch the output mode
from judgment mode to BCD mode so that measured values are
output instead of judgment results.
Setting on the instrument: See p. 184.
Setting with a communications command:
See LCR application dikc - Communications command (
IO:BCD
).
