Checking the Contents of a File
8.7 Checking the Contents of a File
This section describes how to check measurement data les (CSV), screen copy les (BMP), set-
tings les (SET), and panel save les (PNL) saved on a USB ash drive on the instrument’s screen.
Screen display method (For more information, see p. 29.):
(Measurement screen) FILE key>(FILE screen) LIST tab
1
Insert the USB ash drive into the front
USB connector (p. 138).
2
Select a le with the  keys and
touch the VIEW key.
1
2
If the selected le is a folder (FDR), the SE-
LECT key will be displayed. Touching this key
will display the les in the folder.
The le’s contents will be displayed.
CSV le
BMP le
SET le
PNL le
3
Touch the EXIT key twice.
Displays the measurement screen.
