Checking the Contents of Files on a USB ash drive
8.2 Checking the Contents of Files on a USB ash
drive
This section describes how to display les and check their contents.
Screen display method (For more information, see p. 29.):
(Measurement screen) FILE key>(FILE screen) LIST tab
Displays the measurement screen.
Allows you to change the sorting order by
touching the FILE NAME, DATE, or SIZE.
: Ascending order
: Descending order
File size
File save date and time
File format
FDR: folder, CSV: text data (CSV format),
BMP: screen copy data,
SET: instrument set-
tings data, PNL: panel data
File name
Information of the USB ash drive.
Allows you to conrm details by touching
this information (p. 160).
Recognizing the USB ash drive: blue
USB is being accessed : red p. 138)
The instrument can recognize le names of up to 127 single-byte characters.
8
Using USB Flash Drive (Saving and Loading Data)
