10.5 Interfaces
Display
Display 5.7-inch VGA color TFT LCD (640 × 480 dots)
Dot pitch 0.06(W)mm×0.18(H)mm
Touch panel Analog resistive lm type
EXT I/O connector
Connector D-sub 37-pin female #4-40 inch thread
Input signal Photocoupler-isolated, no-voltage contact input
Input ON voltage : 0 V to 0.9 V
Input OFF voltage : OPEN, or 5 V to 24 V
Maximum input voltage: 30 V
Output signal Photocoupler-isolated, Nch open drain output
Maximum load voltage : 30 V
Maximum output current: 50 mA/CH
Residual voltage : 1 V or less (50 mA)
Built-in isolated power sup-
ply
Voltage : 4.5 V to 5 V
Maximum output current: 100 mA
Floating relative to protective ground potential and measurement circuit
Pin and signal assignments See "Instrument connector signal assignments" (p. 162).
Rear USB connector
Connector USB Type B receptacle
Electrical specications USB2.0 (High Speed)
Number of receptacles 1
Front USB connector
Connector USB type A
Electrical specication USB2.0 (High Speed)
Bus power Max. 500 mA
Number of ports 1
Supported USB ash drives USB Mass Storage Class compatible
Functions • Saves measured values, measurement conditions, correction values,
instrument settings, and screen data.
• Loads previously saved measurement conditions, correction values, mea-
sured values, instrument settings, and screen data.
