About Measurement Times and Measurement Speed
10.7 About Measurement Times and Measurement
Speed
Measurement times vary with the measurement conditions (see the table below). Values are all
provided for reference purposes only (and vary with operating conditions).
Analog measurement signal (INDEX
―― ― ― ―
)
Measurement speed
Measurement
frequency
FAST MED SLOW SLOW2
DC (line frequency 50 Hz) 1 ms 20 ms 100 ms 400 ms
DC (line frequency 60 Hz) 1 ms 16.67 ms 100 ms 400 ms
4.00 Hz to 10.00 Hz Tf 2×Tf 3×Tf 4×Tf
10.01 Hz to 39.99 Hz Tf 2×Tf 5×Tf 10×Tf
40.00 Hz to 99.99 Hz Tf 2×Tf 5×Tf 40×Tf
100.00 Hz to 300.00 Hz Tf 2×Tf 5×Tf 50×Tf
300.01 Hz to 500.00 Hz Tf 2×Tf 10×Tf 200×Tf
500.01 Hz to 1.0000 kHz Tf 5×Tf 20×Tf 300×Tf
1.0001 kHz to 2.0000 kHz Tf 8×Tf 40×Tf 600×Tf
2.0001 kHz to 3.0000 kHz 2×Tf 12×Tf 60×Tf 1200×Tf
3.0001 kHz to 5.0000 kHz 3×Tf 20×Tf 100×Tf 2000×Tf
5.0001 kHz to 10.000 kHz 5×Tf 40×Tf 200×Tf 3000×Tf
10.001 kHz to 20.000 kHz 10×Tf 80×Tf 400×Tf 6000×Tf
20.001 kHz to 30.000 kHz 25×Tf 150×Tf 600×Tf 12000×Tf
30.001 kHz to 50.000 kHz 25×Tf 250×Tf 1000×Tf 20000×Tf
50.001 kHz to 100.00 kHz 50×Tf 400×Tf 2000×Tf 30000×Tf
100.01 kHz to 140.00 kHz 100×Tf 800×Tf 4000×Tf 60000×Tf
140.01 kHz to 200.00 kHz 100×Tf 800×Tf 4000×Tf 60000×Tf
200.01 kHz to 300.00 kHz 250×Tf 1500×Tf 6000×Tf 120000×Tf
300.01 kHz to 400.00 kHz 250×Tf 2500×Tf 10000×Tf 200000×Tf
400.01 kHz to 500.00 kHz 250×Tf 2500×Tf 10000×Tf 200000×Tf
500.01 kHz to 700.00 kHz 500×Tf 4000×Tf 20000×Tf 300000×Tf
700.01 kHz to 1.0000 MHz 500×Tf 4000×Tf 20000×Tf 300000×Tf
1.0001 MHz to 1.4000 MHz 1250×Tf 8750×Tf 40000×Tf 600000×Tf
1.4001 MHz to 2.0000 MHz 1250×Tf 8750×Tf 40000×Tf 600000×Tf
2.0001 MHz to 3.0000 MHz 1875×Tf 15000×Tf 60000×Tf 900000×Tf
3.0001 MHz to 4.0000 MHz 2500×Tf 25000×Tf 100000×Tf 1500000×Tf
4.0001 MHz to 5.0000 MHz 2500×Tf 25000×Tf 100000×Tf 1500000×Tf
5.0001 MHz to 6.0000 MHz 5000×Tf 40000×Tf 156250×Tf 2500000×Tf
6.0001 MHz to 8.0000 MHz 5000×Tf 40000×Tf 156250×Tf 2500000×Tf
• Tf [sec]: 1/measurement frequency [Hz]
• The above DC measurement times apply to operation with DC adjustment off. To calculate times for opera-
tion with DC adjustment on, multiple the above times by 2 and add 0.5 ms.
